Tamiya 47480 M08R/M-08R Concept Chassis Assembly Kit, NIB **Pre-Order**
Sale
£259.00
£299.99
TTP Models
Official UK licensed supplier of brand-new genuine vintage and current Tamiya Parts, Spares & Hop-Ups to radio-controlled car enthusiasts around the world. We stock the largest range of genuine Tamiya RC parts on ebay worldwide. Free combined postage*. New items are added every day.
Any currently available 5, 7 or 8 digit part can be specially ordered, please message us with your requirements.
**Pre-order. Due end of July**
Tamiya M08R/M-08R Concept Chassis Kit, Kit No. 47480
Description:
The M-08R adds a plethora of race-spec parts to the balanced, compact RWD M-08 Concept chassis: an example being the hopped-up drivetrain with a ball differential, universal shafts featuring low-friction cross joints and lightweight aluminium swing shafts, plus 5mm wheel hubs. Turnbuckle shaft suspension arm and steering setup components simplify fine-tuning of the M-08R, and titanium-coated shafts are a durable inclusion in the kit. Carbon fibre damper stays are paired with M-Chassis big bore aluminium dampers+ featuring dedicated blue anodized top and bottom caps for a touch of class, while a 20-gram ballast weight is included to get the chassis feeling just how you want it to.
Featured Drivetrain Components
-
Full ball bearings
-
Ball differential (52T)
-
33mm lightweight aluminium swing shafts
-
Cross joint for LF assembly type universal shafts
-
06 module fluorine coated 20T pinion gear
-
M-08 Concept aluminium shafts
-
M-Chassis reinforced freewheel axles
-
5mm clamp-type wheel hubs
-
Suspension
-
Carbon fibre damper stays (front/rear)
-
Reinforced D parts (suspension arms)
-
Aluminium turnbuckle shafts
-
Titanium coated suspension shafts
-
5x5mm, 5x11mm hard hex head ball connectors
-
M-Chassis big bore aluminium dampers+
-
3x 1.3mm-hole pistons
-
4mm aluminium serrated wheel nuts (blue)
-
5mm reinforced open face adjusters
Chassis
-
Carbon fibre battery holder
-
Carbon fibre body mount base
-
Reinforced K parts (gearbox)
-
Chassis balance weight (20g)
-
Hi-torque servo saver
-
Aluminium ball connectors (blue)
-
Hex head screws
Specifications
-
Scale is 1:10
-
Length: 319mm (with 225mm wheelbase), width: 165mm
-
Alterable wheelbase: 210mm, 225mm, 239mm
-
Monocoque frame with separate front and rear sections
-
Midship motor, rear-wheel drive
-
Ball differential
-
3-piece steering tie-rod
-
4-wheel double wishbone suspension
-
M-Chassis big bore aluminium dampers+
-
Gear ratio = 5.776:1 (using kit 20T pinion); 8 ratios between 6.795:1 and 4.813:1 are possible with separately sold pinions)
-
Electronic speed controller (ESC) is sold separately.
Separately Required Items
-
Body
-
Type 540 motor (brushless is recommended)
-
Tyres
-
2-channel R/C system w/ESC
-
R6/AA/UM3 batteries for transmitter
-
Battery pack & charger
Postage:
All of our kits come with FREE Tracked 24 hour delivery, with the option to upgrade to a Tracked 24 with signature (requiring to be signed for at point of delivery) - Any kit purchased under the *pre-order* title will be subject to delivery times from the UK importer into us, once received we will then post on to the customer - if you have any questions regarding delivery time, please contact us prior to placing your order.
